The RAM Cable Manager creates an integrated route for electrical wiring and cleanly covers installation holes. A great addition to any surface mounting application. The RAM Cable Manager is made of glass filled nylon which has the benefit of creating a barrier between the RAM Surface Mount and the attachment area; minimizing vibration while reducing fiberglass and gel-coat damage. This item will fit any of the 4" diameter round plates with a 3 hole pattern. (Will not work with the AMPs hole pattern plates)

Compatible RAM Mounts:
Compatible with all 2.25" diameter ball bases that contain a three hole, 120 degree hole pattern.

Dimensions:
Cable slot height: 0.45”
Cable slot width: 0.95”
Max mounting surface thickness: 1.47”

Material:
High Strength Composite and Glass Filled Nylon

IMPORTANT:
To prevent galling of threads during assembly, it is imperative that all threads are lubricated with oil prior to assembly.

Note:
The part number reflects product packaged in retail bag. RAM ball base not included with purchase.
